Honda CBR600F Hurricane Caution Label Hose Routing Diagram OEM 87135MAL850

HONDA Caution label hose routing diagram
87135MAL850 / 87135-MAL-850

Name: Honda Caution Label Hose Routing Diagram OEM 87135MAL850
Brand: Honda
Price: 10 EUR
Availability: InStock

0 reviews - Write a review

Shipping 7-14 days (ETA)

Price check...

Dispatch: 7-14 days (ETA)
Manufacturer: Honda
OEM: 87135-MAL-850
MPN: 87135MAL850
DIAGRAM, HOSE ROUTING

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Additional questions?

Fits models

May fit more models than in this listing.

100% Genuine OEM decal

The genuine OEM decals means they are exactly the same as those fitted at the factory when the vehicle was new. There are absolutely no differences in colour and shape of the sticker.

Description
Reviews

Have you ever struggled to remember the exact plumbing layout of your machine during a maintenance session? The authentic Honda caution label hose routing diagram* is a critical reference point located within the caution label section of your motorcycle. This factory-original decal ensures that every vacuum line and breather hose is routed exactly as the engineers intended for peak performance and reliability.

Restoring the Caution Label Hose Routing Diagram to Factory Standards

✅ Genuine OEM part: This authentic component carries the official manufacturer part number, ensuring it meets the rigorous quality standards set by the factory.
✅ Precision cut: Manufactured using original factory tooling, the decal features clean edges and the exact dimensions required for a perfect fit on your frame or bodywork.
✅ Professional shipping: To maintain structural integrity, your graphic is shipped flat in rigid packaging, preventing any creases or adhesive separation before application.
✅ Original packaging: Each item arrives in official manufacturer packaging, protecting the adhesive surface and the printed diagram until you are ready for installation.
✅ UV resistant: The high-grade vinyl and specialized inks are designed to withstand prolonged sunlight exposure without fading or cracking over time.

Part Number (MPN)	87135MAL850
Manufacturer	Honda
Mounting Location	Caution Label section*
Type	Caution Label
Material	Vinyl decal

Finding genuine Honda stickers for classic models such as the CBR600F Hurricane can be challenging, but using authentic graphics is essential for a true restoration. Choosing this factory-original hose routing diagram reflects a genuine pride of ownership, ensuring your machine remains a faithful representation of its heritage while providing vital technical information for future service.

Frequently Asked Questions

How should I remove an old decal before applying this new one?

To remove an old decal, use a heat gun on a low setting to soften the adhesive, then peel it back slowly. Use a plastic scraper rather than metal to avoid scratching the surface. Clean any remaining residue with isopropyl alcohol before applying your new genuine OEM sticker.

How do I determine the left or right side of the motorcycle?

Sides are always determined from the rider's seated position. The right side corresponds to the throttle grip side, while the left side corresponds to the clutch lever side. This is the universal standard used by manufacturers in all official parts catalogs and diagrams.

Before applying, ensure the surface is de-greased with isopropyl alcohol. Use a plastic squeegee to press from the center outward for a bubble-free finish.

* If this decal is listed under multiple models or versions, the exact mounting location may vary slightly.
